Korg TRITON Le Service Manual

PART CODE PART NAME NOTE
Q
'TY
471102080
CONNECTOR TOP SJ20-08WX KLM-2330 TRITO 1
471102120
CONNECTOR TOP SJ20-12WX KLM-2278/79/80 2
471102130
CONNECTOR TOP SJ20-13WX KLM-2277 TRITO 1
471102130
CONNECTOR TOP SJ20-13WX KLM-2278/79/80 1
471102140
CONNECTOR TOP SJ20-14WX KLM-2278/79/80 1
471102140
CONNECTOR TOP SJ20-14WX KLM-2277 TRITO 1
471102150
CONNECTOR TOP SJ20-15WX KLM-2278/79/80 2
474019500
CONNECTOR 1-215079-6 16P
(
AMP
)
KLM-2330 TRITO 2
474019700
CONNECTOR 76382-404 KLM-1864 TRITO 1
474029500
S.M. CONNECTOR CN015R-3013-0 KLM-2277 TRITO 1
474031000
CONNECTOR B16B-PHDSS KLM-2277 TRITO 1
474033200
SIMM CONNECTOR 404A-072SABA01 KLM-2277 TRITO 2
474033700
CONNECTOR 302A-50PGAS003 KLM-2277 TRITO 1
475002577
HARNESS HNS-2577 TRITON LE61 M. 1
475002969
HARNESS HNS-2969 TRITON LE61 M. 1
475002970
HARNESS HNS-2970 TRITON LE61 M. 1
475003048
HARNESS HNS-3048 TRITON LE61 M. 1
475003049
HARNESS HNS-3049 TRITON LE61 M. 1
475003051
HARNESS HNS-3051 TRITON LE61 M. 1
475003052
HARNESS HNS-3052 TRITON LE61 M. 1
475003053
HARNESS HNS-3053 TRITON LE61 M. 1
475003054
HARNESS HNS-3054 TRITON LE61 M. 1
475003055
HARNESS HNS-3055 TRITON LE61 M. 1
475003058
HARNESS HNS-3058 TRITON LE61 M. 1
475003059
HARNESS HNS-3059 TRITON LE61 M. 1
475102268
HARNESS HNS-2268
(
F
)
L=31CM TRITON LE61 M. 1
475102269
HARNESS HNS-2269
(
F
)
L=25CM TRITON LE61 M. 1
480010380
DIN JACK YKF51-5041 KLM-2277 TRITO 1
500022500
CASE LEG FF-004 TRITON LE61 M. 5
515400100
FUSE HOLDER CNT47-0003A
(
TR
)
KLM-2277 TRITO 2
525001400
FERRITE CORE F5 T 25X12X15 TRITON LE61 M. 1
540023500
AC PLUG ECP01 05A TRITON LE61 UK 1
550018900
X-0180 SPONGE KOC-F40970 TRITON LE61 M. 1
575019700
LED SPACER LH-5-5 L=5MM KLM-2278/79/80 1
620024600
X-952 POWER SW KNOB E40304-2 TRITON LE61 M. 1
620034600
X-631 SVR KNOB
(
GRAY
)
E40239-6 TRITON LE61 M. 1
620034700
X-610 ENCODER KNOB
(
GRAY
)
E40466 TRITON LE61 M. 1
620043900
KNOB P423-9GF
(
-0180
)
E40519-2 TRITON LE61 M. 4
630034200
X-0180 LCD WINDOW KOC-F40962 TRITON LE61 M. 1
630034300
X-0180 REFLECTION FILM F40967 TRITON LE61 M. 1
630034400
X-0180 DIFFUSION FILM F40968 TRITON LE61 M. 1
630034500
X-0180 BLACK FILM KOC-F40969 TRITON LE61 M. 1
641041172
X-323 JACK PLATE 2 KOC-C40963 KLM-2277 TRITO 1
641041648
X-0180 PANEL KOC-C30555 TRITON LE61 M. 1
641041649
X-0180 FRONT BAR KOC-C41228 TRITON LE61 M. 1
641041650
X-0180 BOTTOM COVER KOC-C30557 TRITON LE61 M. 1
641041651
X-0180 REAR OP COVER KOC-C4122 TRITON LE61 M. 1
641041652
X-0180 OP COVER KOC-C41226 TRITON LE61 M. 1
641041653
X-0180 SIMM COVER KOC-C41227 TRITON LE61 M. 1
641041654
X-0180 SUPPORT CHASSIS C30556 TRITON LE61 M. 1
646078700
X-0180 SIDE PLATE L KOC-E10189 TRITON LE61 M. 1

Korg TRITON Le Specifications

General

Polyphony	62 voices
Display	240 x 64 pixel backlit LCD
MIDI	In, Out, Thru
Power Supply	AC adapter (included)
Type	Workstation Keyboard
Keyboard	61 keys
Sound Engine	HI Synthesis
Synthesis Method	PCM
ROM Wave Memory	32 MB
Programs	512 Programs
Drum Kits	24 drum kits
Effects	2 multi-effects processors, 1 master effect, 1 total effect
Sequencer	16-track, 200, 000 notes
Arpeggiator	1 arpeggiator
Storage	SmartMedia card
Outputs	L/MONO, R, Headphones
Floppy Disk Drive	3.5 inch 2DD/2HD
