Korg TRITON Le Service Manual

PART CODE PART NAME NOTE Q'TY
001228700
PCB ASSY KLM-2287 ST-61/76/88 TRITON LE88 M.
1
001233100
PCB ASSY KLM-2331/2332 ST-88 TRITON LE88 M.
1
001238600
PCB ASSY KLM-2386 LE88 TRITON LE88 M.
1
001238700
PCB ASSY KLM-2386 LE88 TRITON LE88 M.
1
304020230
TR 2SC3661-TA/TB
(
3K
)
(
TS
)
KLM-2386 TRITO
10
304020400
TR 2SA1576A T106
(
TS
)
KLM-2386 TRITO
1
304050220
DIGITAL TR DTC114ESA TP
(
TR
)
KLM-2278/79/80
8
304050270
DIGITAL TR DTB113ZSTP
(
TR
)
KLM-2278/79/80
8
304060250
FET CPH6302-TL
(
TS
)
KLM-2386 TRITO
1
312053100
LED NSPW510BS KLM-2278/79/80
1
313005800
LCD MODULE NCM6602B TRITON LE88 M.
1
314001300
DIODE 1SS-133 T-77
(
TA
)
KLM-2331/32 TR
4
314001400
DIODE RLS-73 TE-11
(
TS
)
KLM-2386 TRITO
1
314010300
DIODE 1S2076TD
(
TA
)
KLM-2278/79/80
8
314028800
LED SLZ-190B-09-T2
(
TR
)
KLM-2278/79/80
4
314030500
SCHOTTKY DIODE RB160L-40TE25 KLM-2386 TRITO
1
314030600
DIODE 1SR154-400TE25
(
TS
)
KLM-2386 TRITO
1
314030700
SCHOTTKY DIODE RB051L-40TE25 KLM-2386 TRITO
1
314031000
LED SLR-325VRT31
(
TR
)
KLM-2278/79/80
20
314032000
LED SPR-325MVWT31
(
TR
)
KLM-2278/79/80
1
314032100
ZENER DIODE RD6.8ES T1 AB1
(
TA KLM-2278/79/80
1
315000500
DOUBLE DIODE MC-2840-T12-1
(
TS
)
KLM-2386 TRITO
5
320003217
IC TMP87C847U-4458
(
S
)
KLM-2387 TRITO
1
320004108
IC HD74HC138P KLM-2278/79/80
2
320004681
IC HD6437043AA21F
(
S
)
KLM-2386 TRITO
1
320009001
IC NJM-4558D-V KLM-2331/32 TR
2
320012223
IC MB87F1710PFV-G-BND
(
S
)
KLM-2386 TRITO
1
320012258
IC MBM29F160BE70TN-K
(
BLANK
)
:S KLM-2386 TRITO
2
320040069
MX23L12811TC12X7100BK4H/5H
(
S
)
KLM-2386 TRITO
1
320040070
MX23L12811TC12X7100BK4L/5L
(
S
)
KLM-2386 TRITO
1
320040090
IC MX23C6410MC-10 X-710H-H
(
S
)
KLM-2386 TRITO
1
320040091
IC MX23C6410MC-10 X-710H-L
(
S
)
KLM-2386 TRITO
1
324001015
IC UPC4570G2-E2
(
TS
)
KLM-2386 TRITO
4
324001167
IC UPC78L05T-E2
(
TS
)
KLM-2386 TRITO
1
324003010
IC TC7WU04F TE12L
(
TS
)
KLM-2386 TRITO
1
324003022
IC TC7S04FU
(
TE85L
)
(
TS
)
KLM-2386 TRITO
2
324006007
IC MSM5118165D-60JSR1-9
(
TS
)
KLM-2386 TRITO
3
324007011
IC BA09FP-E2
(
TS
)
KLM-2386 TRITO
1
324007012
IC BA033LBSG-TR
(
TS
)
KLM-2386 TRITO
1
324009058
IC NJU7662M-TE1
(
TS
)
KLM-2387 TRITO
2
324011004
IC M5216FP-600C
(
TS
)
KLM-2386 TRITO
1
324017014
IC RN5VD45AA-TR
(
TS
)
KLM-2386 TRITO
1
324021013
IC SN74LV74ANS-EL
(
TS
)
KLM-2386 TRITO
1
324021015
IC SN74LV08ANS-EL
(
TS
)
KLM-2386 TRITO
1
324021025
IC SN74AHCT240PWR
(
TS
)
KLM-2386 TRITO
1
324021026
IC SN74AHCT541PWR
(
TS
)
KLM-2386 TRITO
4
324021027
IC SN74AHC1G08DBVR
(
TS
)
KLM-2386 TRITO
1
324021030
IC SN74LV04ANSR
(
TS
)
KLM-2386 TRITO
1

Korg TRITON Le Specifications

General

Polyphony	62 voices
Display	240 x 64 pixel backlit LCD
MIDI	In, Out, Thru
Power Supply	AC adapter (included)
Type	Workstation Keyboard
Keyboard	61 keys
Sound Engine	HI Synthesis
Synthesis Method	PCM
ROM Wave Memory	32 MB
Programs	512 Programs
Drum Kits	24 drum kits
Effects	2 multi-effects processors, 1 master effect, 1 total effect
Sequencer	16-track, 200, 000 notes
Arpeggiator	1 arpeggiator
Storage	SmartMedia card
Outputs	L/MONO, R, Headphones
Floppy Disk Drive	3.5 inch 2DD/2HD
