Korg TRITON Le Service Manual

PART CODE PART NAME NOTE Q'TY
324021102
IC SN74LV08APWR
(
TS
)
KLM-2386 TRITO
3
324021103
IC SN74LV32APWR
(
TS
)
KLM-2386 TRITO
2
324021104
IC SN74LV74APWR
(
TS
)
KLM-2386 TRITO
1
324021105
IC SN74LV245APWR
(
TS
)
KLM-2386 TRITO
1
324021106
IC SN74LV139APWR
(
TS
)
KLM-2386 TRITO
2
324021108
IC SN74LV138APWR
(
TS
)
KLM-2386 TRITO
1
324021110
IC SN74LV574APWR
(
TS
)
KLM-2386 TRITO
1
324021114
IC SN74LV05APWR
(
TS
)
KLM-2386 TRITO
1
324021119
IC SN74LV4051APWR
(
TS
)
KLM-2386 TRITO
1
324021121
IC SN74LV541APWR
(
TS
)
KLM-2386 TRITO
3
324021122
IC SN74LV139ANSR
(
TS
)
KLM-2386 TRITO
1
324021123
IC SN74LV125ANSR
(
TS
)
KLM-2386 TRITO
1
324023007
IC S-8520F50MC-B0J-T2
(
TS
)
KLM-2386 TRITO
1
324024001
IC L1087MPX-ADJ
(
TS
)
KLM-2386 TRITO
1
324036008
IC PCM1716E/2K
(
TS
)
KLM-2386 TRITO
2
324045003
IC 93LC66BT-I/SN
(
X16TYPE
)(
TS
)
KLM-2386 TRITO
1
334000600
PHOTO COUPLER PC-410K
(
TS
)
KLM-2386 TRITO
1
335011900
CRYSTAL OSC CA-301 24.576MHZ KLM-2386 TRITO
1
335012400
CRYSTAL OSC CA-301 8MHZ KLM-2386 TRITO
1
335400140
CERAMIC OSC CSTCC8M00G53-R0
(
TS KLM-2387 TRITO
1
350002422
SFR RH0615CJ5J 220K KLM-2331/32 TR
2
350002447
SFR RH0615CS5J 470K KLM-2331/32 TR
2
362009007
VR RK11K1140A9L KLM-2278/79/80
4
365009500
SLIDE VR EWA NA0C10B1 10KB KLM-2278/79/80
1
370005000
REC EC11B15204A5 KLM-2278/79/80
1
374000600
TSW EVQ11A09K
(
TR
)
KLM-2278/79/80
54
375014800
PSW SDKLA10200 KLM-2386 TRITO
1
402002800
COIL 2943-666671 KLM-2278/79/80
2
402004600
COIL 2943-666673 KLM-2386 TRITO
3
402006500
COIL TC-600M-3A-5026 KLM-2386 TRITO
1
402007400
AIR COIL SC-0.5X10X16.5TX4R KLM-2386 TRITO
1
404001050
CHIP INDUCTOR BLM21PG600SN1D KLM-2386 TRITO
2
404001070
CHIP INDUCTOR BLM18BD102SN1D KLM-2386 TRITO
47
404001070
CHIP INDUCTOR BLM18BD102SN1D KLM-2387 TRITO
6
405011500
AC-AC ADAPTOR KA161
(
100V/3.0A TRITON LE88 JP
1
405011600
AC-AC ADAPTOR KA163
(
120V/3.0A TRITON LE88 EX
1
405011600
AC-AC ADAPTOR KA163
(
120V/3.0A TRITON LE88 US
1
405011600
AC-AC ADAPTOR KA163
(
120V/3.0A TRITON LE88 CN
1
405011700
AC-AC ADAPTOR KA169
(
230V/3.0A TRITON LE88 GE
1
405011700
AC-AC ADAPTOR KA169
(
230V/3.0A TRITON LE88 FR
1
405011700
AC-AC ADAPTOR KA169
(
230V/3.0A TRITON LE88 WG
1
405011700
AC-AC ADAPTOR KA169
(
230V/3.0A TRITON LE88 UK
1
405011800
AC-AC ADAPTOR KA165
(
240V/3.0A TRITON LE88 AU
1
420007000
88NOTE TP/31+PCB+AFTH TRITON LE88 M.
1
450003100
PHONE JACK LGR4609-7000 KLM-2278/79/80
1
454004300
PHONE JACK YKB21-5012 KLM-2386 TRITO
4
454009900
PHONE JACK YKB21-5074G KLM-2386 TRITO
3

Korg TRITON Le Specifications

General

Polyphony	62 voices
Display	240 x 64 pixel backlit LCD
MIDI	In, Out, Thru
Power Supply	AC adapter (included)
Type	Workstation Keyboard
Keyboard	61 keys
Sound Engine	HI Synthesis
Synthesis Method	PCM
ROM Wave Memory	32 MB
Programs	512 Programs
Drum Kits	24 drum kits
Effects	2 multi-effects processors, 1 master effect, 1 total effect
Sequencer	16-track, 200, 000 notes
Arpeggiator	1 arpeggiator
Storage	SmartMedia card
Outputs	L/MONO, R, Headphones
Floppy Disk Drive	3.5 inch 2DD/2HD
