Korg Triton Studio Service Manual

1
x4
1
1
1
x2
2
2
3
4
4
4
4
5
5
x3
x3
x3
x6
x2
x4
TRITON-ST PANEL
x6
NO
PART CODE
PART NAME Q'TY
1 620044200 X-610 2 LINKAGE KNOB A-2-WG 13
2 620044300 X-610 2 LINKAGE KNOB A-1-WG 4
3 620044400 X-610 2 LINKAGE KNOB B-2-WG 6
4 620044500 X-610 2 LINKAGE KNOB B-1-WG 7
5 620044700
KNOB P423-95MO (BK L/CGRAY B)
7

Korg Triton Studio Specifications

General

MIDI	In, Out, Thru
Type	Workstation
Polyphony	62 voices
Oscillators	2 oscillators per voice
Effects	2 master effects
Sequencer	16-track
Sampling	16-bit, 48 kHz, expandable RAM (optional EXB-SMPL board)
Display	TouchView graphical interface
Storage	Internal hard drive, floppy disk drive
Keyboard	61, 76, or 88 keys with velocity and aftertouch
Sound ROM	32 MB (expandable with EXB series)
Outputs	stereo main outputs
Inputs	L/Mono, R
