Rear Panel
7. Digital Coaxial Input
For connecting external equipment that has a digital coaxial output jack.
8. Digital Coaxial Output
For connecting external equipment that has digital audio input jack, such as a CD Recorder.
9. S - Video Output
For connecting the S-VIDEO IN jack on the TV using an optional S-Video cable. This type of connection will
provide superior picture quality. However, your TV must be equipped with an S-Video input socket.
10. Video Output - TV
For connecting to TVs (Most TVs have this type of connection. If your TV has Component Video or S-Video,
you will get a better picture by using them instead).
11. Digital Optical Input
For connecting external equipment that has a digital optical output jack.
12. Subwoofer Speaker (Included)
Connect the included subwoofer with colored wire to “+” and black wire to “-”.
13. Surround Speaker (Left & Right)
For connecting the left surround speaker to “SL” terminals and right surround speaker to “SR” terminals.
Connect the colored wire to “+” and black wire to “-” .
14. Front Speaker
For connecting the left front speaker to “L” terminals, right front speaker to “R” terminals and center
speaker to “C” terminals. Connect the colored wire to “+” and black wire to “-”.
15. Surround Back Speaker
For connecting the surround back speaker to “SB” terminal. Connect the colored wire to “+” and black
wire to “-” .
16. Active Subwoofer Out (for optional powered subwoofer)
For connecting an optional external powered subwoofer.
17. Power Cord
