Setup and Installation
The following setup and installation diagrams show the different video and audio connections to TV, VCR or CD
Recorder.
Important
Make sure the AC Voltage matches your local voltage.
Connect the AC cord only after the speakers, antennas, and all optional equipment have been
connected.
(1) Video Connections
NOTE: When in AV1 or AV2 mode, only composite video sources will have video output
signal, therefore, connect only RCA video output or TV Out to your TV sets.
VCR VIDEO OUT
VCR VIDEO IN
To Next Page
