Kozi 100 - Detailed Parts List

Page 22
Item No. Description Part No.
1 Pedestal Base Assembl
y
(
Black
)
10009
Not Shown Gold, Side Trims 10027
2 Front Grill 10010
3 Top Lid (Black) 10022
4Ho
pp
er Lid
(
Black
)
10023
5 Back Cover Plate (Black) 10021XL
6To
p
Heat shield –Burn Chamber 10011XL
7 Back Heat Shield – Burn Chamber 10012XL
Not Shown Right Heat Shield – Burn Chamber 10013-1XL
Not Shown Left Heat Shield - Burn Chamber 10013-2XL
Not Shown Right Side Panel (Black) 10020
Not Shown Left Side Panel
(
Black
)
10019XL
8 Auger Chute Gasket Kit 10006-12
9 Circulation Fan Gasket 10036-1
10 Exhaust Housing Mounting Gasket 10002XL
Not Shown Exhaust Fan Mountin
g
Gasket 10002-1XL
Not Shown Exhaust Fan Motor Mounting Gasket 10031-1
Not Shown Door Ro
p
e Gasket 10025-2
Not Shown Ash Tray Rope Gasket 10017-3
11 Auger Motor 10035
12 Feed Control Switch 10044
13 Push Button Start 10043
14 Circulation Fan S
p
eed Control 10038
15 Circulation Fan Override, Thermal disk 10037
16 Manual Reset, Overheat Thermal disk 10039
17 Exhaust Fan 10031
18 Exhaust Tem
p
erature Thermal disk. 10034XL
19 Static Pressure Switch 10032
20 Static Pressure Switch Tube 10033XL
21 Auto/Manual Timer 10041
22 Electrical Cord 10042
23 Auger Cycle Timer 10040
24 Trouble Shootin
g
Module Li
g
ht 10046
25 Circulation Fan 10036
26 Wiring Harness 10045XL
27 Exhaust Housin
g
Box 10002XL
28 Damper Kit (Includes Damper, Coil Handle, Slide Bracket, Rubber Slider) 10004XL
29 Exhaust Tube Assembl
y
10026
30 Cleaning Rod (Includes Coil Handle) BV22
31 Com
p
lete Door Assembl
y
(
Black
)
10025
31 Complete Door Assembly (Gold) 10025
Not Shown Door Handle Kit 10025-4
32 Door Glass 10025-5
33 Ash Tra
y
10017XL
Not Shown Ash Tray Knob 10017-2XL
34 Glass Holder Kit 10025-3
35 Burner Pot 10016XL
36 Burner Pot Stand 10014XL
37
Auger Rebuild Kit (Includes bushings, auger, auger holder, auger holder
gasket, nut and bolt…)
10006-7, 10008,
10008-4, 10035-1
38 Com
p
lete Ho
pp
er/Au
g
er Assembl
y
10006
Not Shown Pedestal Gold Molding 10009-3
Not Shown
KOZI
Logo 10009-4
Panels & Trims
Gaskets & Gasket Kits
Electrical Com
p
onents
Kits, Assemblies & Other Com
p
onents
4. Parts List
