page 11Caesar 12’x14’ assembly manual
M7
1#
M7
M7
M7
Parts Required:
P2
P2
Q4
K4
Q4
1#
R
M7
②
②
③
③
M7 x4
R x4
1#
x20
X4
X4
X4
M7
K4
M7
M7
M7
1#
P2 x2
Q4 x2
1. Connect the Inner Roof Connector (Part K4) with the Corner Roof Bar (Part M7) using screws 1#.
2. Attach Corner Roof Bar(Part M7)
to main frame using screw 1#
as shown in the diagram.
3. Attach Finishing Bar (Part P2, Q4) with
Finish End (Part R) using screws 1# to
Corner Roof Bar (Part M7) as shown
in the diagram.
