page 13Caesar 12’x14’ assembly manual
Parts Required:
K14 x1
1#
x2
K14
K4
1#
1#
K14
Tips: Do not tighten these two screws completely before step 12,
only after puting all upper panels in place,then tighten them thoroughly.
Upward View
Step 10: Connect Outside Roof Connctor
Connect Outside Roof Connector (Part K14) to Inside Roof (Part K4) using screw
1# as shown in the diagram.
To Next Page
