5.6 MAIN MENU
The main menu consists of five main headings Show, Charge control, Alarm,
Settings and Advanced. Use the “↓” and “↑” buttons to browse through the
main headings. Ensure that the Select action option is highlighted and then
press the OK button to continue to the selected main heading.
A set of main headers is concealed behind the Advanced main heading.
These manage the test and calibration functions and basic selections of functions and basic data.
If PCM2 is used solely as a monitor (number of rectifiers = 0) the Charge control option cannot be
selected.
WARNING! The settings under the Advanced heading are critical for the functionality of the
system. Start by reading carefully through the instructions in this manual. Then only change if you
are absolutely sure about what you are doing!
5.7 SHOW
5.7.1 General
Under the Show header there is a presentation of status in the form of
measurement values and other operating data from battery, rectifier and the
general system. This includes displaying certain operating statistics.
If PCM2 is used solely as a monitor (number of rectifiers = 0) the Rectifier option cannot be
selected.
5.7.2 Show battery related data
Shows battery terminal voltage, battery mid voltage and battery temperature.
The mid voltage and temperature are only shown if relevant measuring
sensors are installed. This is controlled in the Functions menu, see sections
5.13.3 and 5.13.4.
5.7.3 Show rectifier
5.7.3.1 Show voltage and current
Show the voltage and current that each rectifier unit measures and reports to
the monitoring unit.
To show more detailed information on a rectifier unit, select the Detail action
option.
5.7.3.2 Show detailed rectifier data
Available data from the rectifier unit are different between different rectifier models.
Rectifier module type PCS and newer models of PRM3
Available data from the rectifier unit are stored in a 16 bits status word. The
row with individual bits starts with bit 15 to the left and ends with bit 0 to the
right. The row below shows the status word in decimal form in three ways. In
the middle is the value of the complete 16 bits word, to the right the lower 8
bits of the word and to the left the upper 8 bits of the word. A table that
describes the individual bits is found in Appendix_C
=====MAIN MENU=====
Show
Charge control
Alarm
Settings
Advanced
________________________________
Select Return
=======SHOW=======
Battery
Rectifier
Insulation
Statistics
Program version
________________________________
Select Return
=SHOW/RECTIFIER=
Rect1: 120.4V 6.43A
Rect2: 120.4V 6.43A
Rect3: 120.4V 6.43A
Rect4: 120.4V 6.43A
________________________________
Detail Return
===SHOW/BATTERY===
Ubattery: 120.4V
Umid: 60.2V
Temperature: +22°C
________________________________
Return
Rectifier No 1:
Parameter Status
0000 1000 0000 0111
08 2055 07
________________________________
Return
To Next Page
