temperature controlled.
Note that the voltage is limited to maximum 1% below the level U
maximum
, see section 5.13.8.
WARNING! Batteries and load can be damaged by incorrectly set equalizing charging voltage.
Always observe the recommendations and relevant installation specifications given by the battery
manufacturer.
5.10.4 Adjust the current limit value
Set the required level for the rectifier's current limit. The level is set as a
percentage of rated current.
5.10.5 Adjust clock
After all power to the monitoring
unit has been cut, the clock must
be set, see also section 5.5.5. But
even after an extended period of
normal operation, the clock may
ultimately need to be adjusted.
The most important function of the clock is for a time
stamp of alarm events. In order for time stamping to be
reliable, it is therefore good practise to check that the
clock is correct from time to time.
Minute, hour, day, month and year are adjusted
individually in sequence.
5.11 ADVANCED
A set of main headers is concealed behind the
Advanced main heading. These manage the test
functions and calibration options, basic selections of
functions and basic data and a service condition.
WARNING! The settings under the Advanced heading are critical for the functionality of the
system. Read the manual carefully first. Then change only if you are absolutely sure about what
you are doing!
5.12 TEST & CALIBRATE
5.12.1 General
The functions under the Test&Calibrate are primarily designed for use during
commissioning and service.
5.12.2 Show status for digital inputs
Shows the current status for the monitoring unit's digital inputs. The 6.4.4
section has a more detailed description of the digital inputs.
=====ADVANCED=====
Do you want to
go to advanced
settings?
________________________________
Yes No
=ADVANCED/TEST&CAL=
Show digital in
Test digital out
Calibrate Ubattery
Calibrate Umid
Lamptest
________________________________
Select Return
=====ADVANCED=====
Test&Calibrate
Functions
System data
Service
________________________________
Select Return
====././SHOW DIG.IN===
EQ disable: open
EF Bl./Test: closed
Fuse fault: closed
Ext. fault: closed
________________________________
Return
Adjust
current limit level
limit
100%
________________________________
Ready
2018-10-16 12:10:47
Adjust clock,
day:
16
________________________________
Ready
2018-10-16 12:10:47
Adjust clock,
hour:
12
________________________________
Ready
2018-10-16 12:10:47
Adjust clock,
minute:
10
________________________________
Ready
2018-10-16 12:10:47
Adjust clock,
month:
10
________________________________
Ready
2018-10-16 12:10:47
Adjust clock,
year:
2018
________________________________
Ready
