Your 401C and 401DN
4
4 Your 401C and 401DN
This section describes the 401C and the 401DN.
4.1 Your 401C
Figure 1 and Table 1 describe the 401C:
Figure 1: 401C Y/C to Composite Converter / DA
Table 1: 401C Y/C to Composite Converter / DA Features
# Feature Function
1 12V DC +12V DC connector for powering the unit
2 CV OUT BNC Connectors Connect to the composite video acceptors (1 and 2)
3 Y/C OUT 4p Connectors Connect to the s-Video acceptors (1 and 2)
4 Y/C IN 4p Connector Connect to the s-Video source
5 ON Lights when the power is connected
