3.1 Defining the FC-70R RS-232 to USB Converter
This section defines the FC-70R.
Figure 1: FC-70R RS-232 to USB Converter
#
Feature
Function
1
RS-232 Terminal Block
Connects to a control device
2
USB-B Connector
Connects to a KVM or KVM combiner being controlled
3
ON LED
Lights when the device is powered on
4
MOUSE USB-A Connector
Connects to a USB mouse
5
KB USB-A Connector
Connects to a USB keyboard
