KDS-8 – Defining KDS-8 SDVoE Streaming Transceiver
5
#
Feature
Function
HDMI IN Connector
Encoder mode: Connect to a video source for streaming.
Decoder mode: Connect to a video source for a local video input.
10GbE (PoE) RJ-45
Connector
Connect to another SDVoE
TM
unit or to another device for streaming
video.
AUDIO 3.5mm Jack
Encoder mode: Connect to an unbalanced analog audio source for
embedding audio in the streaming signal.
Decoder mode: Connect to an unbalanced analog audio acceptor for
de-embedding audio from the streaming signal.
IR OUT 3.5mm Jack
Connect to a 38kHz IR transmitter for transmitting the IR signal that was
extended via the streaming line. For example, connect to an IR
transmitter to control a display.
IR IN 3.5mm Jack
Connect to a 38kHz IR sensor for extending the IR signal via the
streaming line.
RS-232 3-Pin Terminal
Block
Connect to a serial controller or controlled device for extending the serial
control signal via the streaming line to an external device.
SERVICE Mini USB
Connector
For internal use.
1GbE LAN RJ-45
Connector
Connect to a 1G device.
12V DC Connector
Connect to the power adapter.
