Configuring Settings – OSD
The configuration OSD enables you to configure KDS-8. When using the menu, it appears as
an overlay on top of any image that appears on the display. The menu is operated using the
front panel buttons.
KDS-8 configuration OSD enables performing the following:
• Navigating Configuration OSD on page 10.
• Configuring Information OSD on page 12.
• Defining Configuration OSD Duration on page 13.
• Defining EDID on page 13.
• Defining HDCP on page 13.
• Changing Encoder/Decoder Mode – OSD on page 13.
• Defining Cooling Fan Operation on page 14.
• Selecting Active Input on page 14.
• Setting Overlay Priority on page 14.
• Verifying Device Information on page 15.
Navigating Configuration OSD
Navigate the configuration OSD using the four OSD Navigation Buttons on the front panel,
as follows:
• MENU button – Open the configuration OSD on your screen or exit a menu option.
When KDS-8 is in encoder mode the OSD appears on the bottom left of the screen and
when it is in decoder mode it appears on the bottom right of the screen.
• + or – buttons – Move up or down in the menu / sub-menu or scroll through parameter
options.
• INFO/ENTER button – Open a menu / sub-menu item, activate a menu / sub-menu item
to edit it or select the required value.
When a menu item is selected, it turns green.
When a menu / sub-menu item is activated and editable, the item turns red.
For example, to change the local priority setting:
1. Press the Menu button.
