Kramer ProScale VP-728 User Manual

VP - 728
TECHNICAL SPECIFICATIONS
INPUTS:
4 universal Y/CV, Pb/C, Pr (composite, s−Videoandcomponent)1Vpp/75ΩonRCAconnectors;
2 UXGA on a 15−pin HD connector (VGA through UXGA);
2 HDMI connectors;
1 USB connector;
Foreachuniversalinputthereisacorresponding(unbalanced)audiostereoinput(1Vnom./25kΩ
minimum)anddigitalstereoS/PDIFinput(32kHzto96kHzsamplefrequency/75Ω)onRCA
connectors;
For each UXGA input there is a corresponding (unbalanced) audio stereo input on a 3.5mm mini
jack connector.
OUTPUTS:
1 HDMI connector;
1 UXGA format on a 15−pin HD connector;
1unbalancedaudiostereooutput(1Vnom./50Ω)onRCAconnectors;
1digitalstereoS/PDIFoutput(32kHzto96kHzsamplefrequency/75Ω)onanRCAconnector.
COMPLIANCE
WITH HDMI
STANDARD:
Supports HDMI and HDCP.
OUTPUT
RESOLUTION:
Native HDMI, 640x480x60Hz, 640x480x75Hz, 800x600x50Hz, 800x600x60Hz, 800x600x75Hz,
1024x768x50Hz, 1024x768x60Hz, 1024x768x75Hz, 1280x768x50Hz, 1280x768x60Hz,
1280x720x60Hz, 1280x800x60Hz, 1280x1024x50Hz, 1280x1024x60Hz, 1280x1024x75Hz,
1366x768x50Hz, 1366x768x60Hz, 1400x1050x50Hz, 1400x1050x60Hz, 1600x1200x50Hz,
1600x1200x60Hz, 1680x1050x60Hz, 1920x1080x60Hz, 1920x1200x60Hz, 480px60Hz, 576px60Hz,
720px50Hz, 720px60Hz, 1080ix50Hz, 1080ix60Hz, 1080px50Hz, 1080px60Hz, 720x480x59.94Hz,
1280x720x59.94Hz, 1920x1080ix59.94Hz, 1920x1080x23.98Hz, 1920x1080x29.97Hz,
1920x1080x59.94Hz or custom.
CONTROL:
Front panel buttons/OSD, IR remote control, RS−232 on a 9−pin D−sub connector.
ADDITIONAL
CONTROLS:
Picture−In−Picture: Video−in−Graphics (or vice versa), Picture−and−Picture or Split Screen (two
images side− by −side), freeze, zoom, different selectable vertical refresh rates, video and audio
ProcAmp control, output image scaling and aspect ratio change, EDID capture, text overlay, slide
show.
POWER
CONSUMPTION:
100−240V AC, 50/60Hz, 30VA automatic power supply.
DIMENSIONS:
19" x 9.3" x 1U W, D, H, rack mountable.
WEIGHT:
3kg (6.6lbs) approx.
ACCESSORIES:
Null−modem adapter, rack “ears” , IR remote control, 2 sets of C− SF/2RVM −0.5 cables, power cord,
control application program via RS−232 (PC) and via Ethernet (i−Phone® and PC).
