8 PT-101H4 - Technical Specifications
6 Technical Specifications
INPUT: 1 HDMI connector
1 Ethernet on an RJ-45 TP connector
OUTPUTS: 1 HDMI connector
1 S/PDIF on an RCA connector
MAX. DATA RATE: Supports up to 2.25Gbps per graphic channel
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI and HDCP
POWER SOURCE: 5V DC, 450mA
OPERATING TEMPERATURE: 0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE: -45° to +72°C (-49° to 162°F)
HUMIDITY: 10% to 90%, RHL non-condensing
DIMENSIONS: 6.2cm x 5cm x 2.4cm (2.44" x 1.97" x 0.94"), W, D, H
WEIGHT: 0.3kg. (0.67lbs) approx.
ACCESSORIES: Power supply
OPTIONS: RK-4PT 19" rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com
