PT-101H4 - Overview 3
3 Overview
The PT-101H4 is a high−performance repeater and format converter for HDMI
signals. The unit combines previous HDMI formats and Ethernet to provide HDMI
(v1.4 HEAC) and de−embedded audio over S/PDIF.
The PT-101H4 HDMI Repeater and Format Converter:
• Extends the transmission range to up to 35m (115ft) with 1080p @60Hz
resolution
• Features reclocking and equalization
• Provides HDMI support on the output
• Supports up to 2.25Gbps bandwidth
• Combines an HDMI 1.3 signal with Ethernet to produce an HDMI (1.4 HEAC)
signal
For Ethernet connectivity, an HDMI 1.4 version output cable must be used.
• Outputs S/PDIF audio from the Audio Return Channel of the HDMI output
signal
• Passes the HPD (Hot Plug Detect) and CEC (Consumer Electronics Control)
signals from the display to the source device
• Provides EDID PassThru—Passes EDID/HDCP signals from source to
display
3.1 About HDMI—General Description
High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital
audio/video interface, widely supported in the entertainment and home cinema
industry. HDMI ensures an all-digital rendering of video without the losses associated
with analog interfaces and their unnecessary digital-to-analog conversions. It delivers
the maximum high-definition image and sound quality in use today. Note that Kramer
Electronics Limited is an HDMI Adopter and an HDCP Licensee.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC.
