TP-202 - Technical Specifications
5 Technical Specifications
INPUT:
1 CAT 5 LINE IN on an RJ-45 connector
OUTPUTS:
1 CAT 5 LINE OUT on an RJ-45 connector
2 UXGA on 15-pin HD connectors
MAX. OUTPUT LEVEL:
1.5Vpp
RESOLUTION:
Up to UXGA, up to 1080p
DIFF. GAIN:
2.8%
DIFF. PHASE:
0.2Deg
K-FACTOR:
0.1%
S/N RATIO:
69.2dB @5MHz
CONTROLS:
Level: -9.6dB to +2.3dB; Equalization: 0dB to 36.3dB
@50MHz
COUPLING:
Receiver section: DC, looping section: AC
POWER CONSUMPTION:
12V, 525mA maximum current (when feeding TP-219HD
(as the transmitter) and a looped TP-202)
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95"), W, D, H
WEIGHT:
0.3kg (0.67lbs) approx.
ACCESSORIES:
Power supply
OPTIONS:
RK−3T 19" rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com
