Note:
Terminate unused inputs to 75Ω, and terminate active inputs at the
connecting source
The output signal format must match the input signal format (for example, if
the input is composite, the output is composite)
All signal cables to each device should be of equal length (for example, the
R,G,B cables between a camera and the amplifier should be of equal length)
