In order to facilitate handling of the K 1050 TS T, the following pages are
intended to further explain its use.
Description of high pressure cleaner
Contents ........................................................................................................ 28
Description of high pressure cleaner ................................................ 29
Explanatory symbols ..................................................................................31
General rules ............................................................................................... 32
Safety precautions ................................................................................... 33
Functional details ..................................................................................... 36
Putting into operation ..............................................................................40
To shut down the pump .......................................................................... 44
Small repairs - do it yourself!................................................................ 45
EC declaration of conformity ................................................................ 49
Warranty ........................................................................................................ 50
Design
The KRÄNZLE K 1050 TS T high pressure cleaner is a mobile machine with an
advanced arrangement system. Please see construction scheme for more details.
1 Ergonomically shaped handle
2 Pump head made of brass
3 Hose drum
4 Start/Stop switch with pressure
relief for HP hoses
5 Water connection supply with filter
6 Storage for trigger gun with
lance on back
7 Trigger gun with safety catch
8 Lances in storage
9 On/O switch
10 Large stair climbing wheels
11 Cable reel
12 Power supply cable with plug
1
2
3
4
8
5
6
7
9
10
11
12
