48 49
Small repairs - do it yourself! EC declaration of conformity
The water from the lance comes in
squirts. The HP hose vibrates.
Proceeding:
Unscrew all 6 valves, one after the other
(hexagonal brass screws, 3 in a row,
vertically and horizontally)
Take out valve body (with green or red
plastic coating) and O-ring by means
of needle nose pliers. Check O-ring for
damage. In case of a damage the O-ring
has to be replaced.
Take a wire (paper clip) and clean valves
under running water.
Do not forget the O-ring during
reassembly!
Problem:
Irregular jet from nozzle.
Cause:
Most likely the valves are soiled or sticky.
We hereby declare that the design of the
high pressure cleaners:
Nominal flow:
technical specifications available from:
comply with the following guidelines
and their amendments for high pressure
cleaners:
Sound level measured:
guaranteed:
Applied conformity assessment
procedure:
Applied specifications and standards:
Kränzle 1050 TS T
450 l/h
Fa. Josef Kränzle GmbH & Co. KG,
Mafred Bauer
Rudolf-Diesel-Str. 20, 89257 Illertissen
Machinery directive 2006/42/EC
EMC-directive 2004/108/EC
Noise directive 2005/88/EC, Art. 13
HP water spraying machines
Annex 3, part B, chapter 27
84 dB (A)
87 dB (A)
Annex V, Noise directive 2005/88/EC
EN 60 335-2-79 :2009
EN 55 014-1 :2006
EN 61 000-3-2 :2006
EN 61 000-3-3 :2008
Josef Kränzle
(Managing director)
I. Kränzle GmbH
Elpke 97
D - 33605 Bielefeld
Bielefeld, Apr. 01, 2015
GB
