35
T
erminal strip
Weber-Unimat WT 22 - 551
13,5A excess current release
Motor-Stator
Switch Weber - Amazonas
8 A for K155
KRÄNZLE 155 400 V
olt / 50 Hz
Motor with terminal box
KRÄNZLE 115, 125, 135 230 V
olt / 50 Hz
Wiring diagram
70
μ
F
braun = brown
blau = blue
schw = black
r
t
=
r
e
d
ge = yellow
gn = green
ws = white
34
36
