Kranzle quadro 11/140 TST - Connection Principle

1
2
3
4
8
9
6 Detergent valve
7 High pressure hose
8 Spray gun
9 Interchangeable lance with at jet
nozzle and nozzle protection
10 Interchangeable lance with dirtkiller
1 Water inlet connection with lter
2 Cover for water tank
3 High pressure pump
4 Press. gauge with glycerin lling
5 Unloader valve - safety valve
quadro 12/150
400V/50Hz
Connection principle
The KRÄNZLE quadro 9/170; 11/140 and 12/150 - high pressure cleaners are mobile
machines with hose drum and 20 m industrial hose.
The connection principle can be seen from the illustration.
Components
Description
10
7
6
4
quadro 9/170
quadro 11/140
230V/50Hz
5
