Kranzle quadro 599 TST - Construction and Components

1
2
3
4
8
9
6 Detergent valve
7 High pressure hose
8 Spray gun
9 Interchangeable lance with at jet
nozzle and nozzle protection
10 Interchangeable lance with dirtkiller
1 Water inlet connection with lter
2 Cover for water tank
3 High pressure pump
4 Press. gauge with glycerin lling
5 Unloader valve - safety valve
Connection principle
The KRÄNZLE quadro 599 TST , 799 TST and 899 TST- high pressure cleaners are
mobile machines with hose drum and 20m industrial hose.
The connection principle can be seen from the illustration.
Components
Description
10
7
6
4
quadro 599
230V/50Hz
5
quadro 799
quadro 899
400V/50Hz
