Description
Construction and Function
3
8
2
10
12
11
14
5
4
71139 6
14 15 18
19
17
16
8 Storage bin for spray gun and pipe
9 Brake
10 Storage bin for accessories
11 Fuel tank
12 Filler aperture for fuel
13 High pressure outlet
14 Fuel drainage screw
1 Water inlet connection filter
2 Power cable
3 Winder for cable
4 Suction hose for detergent
5 High pressure hose
6 Spray gun
7 Spray pipe attachment
14 Master switch
15 Brief operating instructions
16 Heating switch
17 Thermostat
18 Manometer
19 Detergent dispensing valve
