Kraus Bellucci Series User Manual

11
Step 5. Set up Mounting Brackets
• Turn countertop over and align sink with countertop. Decide location for mounting brackets around the frame at a
distance of about 1/4” (6.4mm) from the edge.
• Mounting holes should be 1/4" from the edge of the sink.
1/4"
(6.4mm)
Step 6. Drill Hole in Countertop
• Use 15/64" drill bit to drill the fixation holes at a depth of 3/8” in the indicated location.
3/8"
15/64 po
Diameter
Depth
Stop
Underneath
the Counter
! CAUTION - To avoid the risk of personal injury, wear safety glasses and cut resistant gloves with
non-slip grip when drilling.
