Diagram and Parts List
A. Spray Head
B. Faucet Body
C. Mounting Hardware
C1. Rubber & Metal
Washer
C2. Mounting Nut
C3. Mounting Screws
D. Supply Hose
E. Hot & Cold Waterlines
E1. Hot
E2. Cold
F. Hose
G. Weight
H. Hex Wrench
I. Quick Connector
Assembly
A
B
C1
C2
C3
D
E1 E2
F
H
G
I
