8
6mm
(1/4") dia.
Step 7: Installing the battery pack
Drill a hole in the wall using a 6mm (1/4 in.)
diamater drill bit. Install the battery pack (K1)
using the molly anchor (K3) and screw (K2)
provided. Insert the battery pack cable (1) into
the control box connection (2).
Step 8: Connect waterlines to main valve
Attach waterlines to angle stops
and tighten until snug. Turn on angles
stops and check for leaks (DO NOT TURN
FAUCET ON)
2
1
K3
K2
K1
NOTE: After installing the battery pack,
the light on the sensor will ash and the
faucet will sound when you move your
hand in the sensor area. If not, check to
ensure the batteries are installed
correctly.
