Kraus Bolden Series - Faucet Dimension

55
Installer Tip:
Shut off main water supply before installing new faucet.
4 1/2"
(116mm)
18"
(456mm)
2 1/4"
(56mm)
6 3/8"
(162mm)
8 3/4"
(221mm)
3 1/2"
(88mm)
Ø1 7/8"
(48mm)
Ø2 1/8"
(54mm)
10 3/4"
(274mm)
22 3/4"
(578mm)
17"
(432mm)
90°
25°
3/8" Compression
Faucet Dimension
