Kraus Bolden Series User Manual

66
Step 1. Remove mounting hardware
Step 2. Install the faucet and mounting hardware
Remove mounting hardware (C1, C2 & C3)
from faucet body (B).
Insert faucet body through the hole in the
sink or countertop.
Install the rubber washer and metal washer
(C1), mounting nut (C2) and mounting
screws (C3) onto the threaded mounting
shank.
Step 3. Secure mounting hardware
Thread the nut (C2) onto the mounting
shank. Lock the nut (C2) into position by
tightening the screws (C3). Do not
overtighten.
B
C1
C2
C3
C1
C2
C3
C2
C3

Kraus Bolden Series Specifications

General

Faucet Type	Pull-Down
Material	Brass
Flow Rate	1.8 GPM
Number of Holes	1
Handle Type	Lever
Number of Handles	1
Number of Holes Required	1
Warranty	Limited Lifetime Warranty
Finish	Multiple finishes available
Installation Type	Deck Mount
Spray Modes	2
Cartridge Type	Ceramic
Certifications	cUPC, NSF
