Kraus Bolden Series User Manual

8
Replacement Parts
Replacement Finish/Color Part #
Parts List
KP12002
*Denotes spray hose assembly color options:
Spray hose assembly color options: Black hose
with Matte Black connector (BLMB), Black hose
with Stainless Steel connector (BLSS),
Gray hose with Chrome connector (GRCH),
Gray hose with Stainless Steel connector
(GRSS), Black hose with Spot Free Stainless
Steel connector (BLSFS), Gray hose with Spot
Free Stainless Steel connector (GRSFS)
**Denotes faucet component color options:
CH - Chrome
SS - Stainless Steel
MB - Matte Black
SSCH - Stainless Steel/Chrome
SSMB - Stainless Steel/Matte Black
SFS - Spot Free Stainless Steel
SFSCH - Spot Free Stainless Steel/Chrome
SFSMB - Spot Free Stainless Steel/Matte Black
1. Spray Head
2. Check Valve
3. Washer
4. Hose
5. Top Spring
6. Sprayer Support Assembly
7. Hose Guide
8. Sleeve
9. Cap
10. Set Screw
11. Cartridge
12. Locking Nut
13. Cartridge Cover
14. Handle
15. Handle Set Screw
16. Cap
17. Base
18. Base O-ring
19. Rubber Washer
20. Metal Washer
21. Mounting Nut & Screws
22. Protective Sleeve
23. Filter Washers
CH,SS,MB,SFS**
1
24. Weight
25. Hex Wrench
GRCH, GRSS,
GRSFS, BLSFS
KP12003
KP12022
KP12023
KP12189
KP12168
KP12004
KP12008
KP12009
KP12010
KP12015
KP12014
KP12013
KP12011
KP12012
KP12009
KP12016
KP12122
KP12018
KP12019
KP12020
KP12021
KP12026
KP12024
KP12028
CH,SS,SFS,MB,
SFSCH, SFSMB
2
3
4
7
5
6
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
CH,SS,MB,SFS**
CH,SS,MB,SFS**
CH,SS,MB,SFS**
CH,SS,MB,SFS**
CH,SS,MB,SFS**
CH,SS,MB,SFS**
BLSS, BLMB*
SSCH, SSMB**

Kraus Bolden Series Specifications

General

Faucet Type	Pull-Down
Material	Brass
Flow Rate	1.8 GPM
Number of Holes	1
Handle Type	Lever
Number of Handles	1
Number of Holes Required	1
Warranty	Limited Lifetime Warranty
Finish	Multiple finishes available
Installation Type	Deck Mount
Spray Modes	2
Cartridge Type	Ceramic
Certifications	cUPC, NSF
