Replacement Parts
A
B
C
D
E
F
ST-2
G
H
A. Strainer Cover
B. Screw 1 5/8"
C. Metal Strainer
D. Foam Gasket
F. Main Body
G. Drain Gasket
H. Drain Nut
Replacement Parts List Finish Part #
KPU00010
KPU00013
KPU00011
KPU00005
KPU00006
KPU00012
KPU00008
KPU00009
E. Rubber Gasket
