Replacement Parts List
3
2
4
1
5
6
7
8
12
9
11
13
1. Spray Head
2. Plastic Sleeve
3. Spray Hose
4. Set Screw
5. Cartridge
6. Locking Nut
7. Cartridge Cover
8. Handle Assembly
9. Quick Connect Assembly
10. Escutcheon
11. Base
12. Weight
13. Hex Wrench Set
(2.5mm & 4mm)
Finish/Color Part #
KP07003
KP07006
KP07007
KP07008
KP07047
KP07102
KP07101
KP07100
KP07000
KP07011
KP07005
KP07001
KP07109
SFS, CH*
*Denotes faucet component color options:
SFS - Spot Free Stainless Steel
CH - Chrome
10
SFS, CH*
SFS, CH*
SFS, CH*
