Replacement Part List
1. Spray Head
2. Plastic Sleeve
3. Spray Hose
4. Set Screw
5. Catridge
6. Locking Nut
7. Catridge Cover
8. Metal Handle
9. A Index Button
B Set Screw
10. Quick Connect
Assembly
11. Cover Plate
12. Putty Plate
13. Base
14. Weight
15. Hex Wrench
(2.5mm)
16. Hex Wrench
(4mm)
1
2
3
4
5
6
7
8
10
14
11
12
13
16
15
9A
9B
