Kreg Jig K5 Master System User Manual

www.kregtool.com
K5 and K5 Master System Parts
Vacuum port
 Acceptsa1¼"(32mm)shopvacuumhoseforefcientchipremoval,swivelssidetoside
Extension Wings
Provide support for wide workpieces and storage for bits and accessories
Screw-length selection guide
Apply this self-adhesive label to the inside of an extension lid for easy reference
Spacer block
In repair applications, positions the drill guide for drilling pocket holes in
¾" (19 mm)-thick material
Pocket-screw sample pack
 Contains10eachofthevemostoftenusedscrews
Pocket-hole plug sample pack
 Containsvepaint-gradewoodplugs
Additional Master System Parts
The K5 Master System includes the following parts
Portable base
Accepts Micro, Standard, and HD drill guide blocks. Useful for large panels or
 assembliesthatwouldbedifculttoclampintoabench-mountedjig.Built-incams 
secure the portable base to your Kreg clamp.
 3"WoodProjectClampwithAutomaxx
®
Provides fast and secure clamping when assembling a pocket-screwed joint. Set
the desired pressure and this 3"-reach clamp automatically adjusts to any
material thickness up to 3" (76mm).
Parts
R
S
T
U
V
W
X
Y
Tocreatestrongjoints,you’llsetyourjigtomatchthe
thickness of the workpiece and the length of the screw.
The Kreg Jig
®
makesthiseasy,injustfoursimplesteps:
Using the Kreg Jig
®
K5 and K5 Master System
