FIGURE 1 FULL POWER BALANCED STEREO AMPLIFIER FRONT PANEL
1 Power Stand-by LED
2 Bias LED
3 Power Button
4 Infrared Sensor
5 Krell CAST LED
6 Regulator LED
1 2 63 54
6 Krell Full Powered Balanced X Series Power Amplifiers
