FIGURE 4 FULL POWER BALANCED MONAURAL AMPLIFIER BACK PANEL
20 Handle
21 Speaker Binding Posts
22 Krell CAST Input
23 Balanced Input
24 AC Mains Power Cord
25 Krell Link Out/In
26 Back Panel Power
Breaker Switch
21 2523 2420 2622
10 Krell Full Powered Balanced X Series Power Amplifiers
