FIGURE 2 FULL POWER BALANCED MONAURAL AMPLIFIER FRONT PANEL
7 Power Stand-by LED
8 Bias LED
9 Power Button
10 Infrared Sensor
11 Krell CAST LED
12 Regulator LED
7 8 129 1110
Krell Full Powered Balanced X Series Power Amplifiers 7
