KREMLIN REXSON 3 Doc. / Dok. : 573.247.050
POMPE PMP 150 MURALE AVEC CIRCULATION WALL MOUNTE D PUMP, MODEL PMP 150
WITH FLUID CIRCULATION
PUMPE PMP 150 WANDANLAGE MIT ZIRKULATION BOMBA PMP 150 MURAL CON CIRCULACIÓN
Ind # Désignation Description Bezeichnung Denominación Qté
1 151 751 000 Pompe PMP 150
murale
Wall mounted pump,
model PMP 150
Wandpumpe PMP 150 Bomba PMP 150 mural 1
2 056 100 199 Panneau de fixation Plate, mounting Wandplatte Pane l de fijación 1
- 151 757 010
Ensemble de circulation
et raccordement
Connecting and f luid
circulation kit
Zirkulationseinheit mit
Anschlüssen
Conjunto de circulación
ydeconexión
1
6 906 314 204  Raccord inox
M1/4BSP-M3/8BSP
 Fitting, st ainless steel,
double male,
1/4 BSP - 3/8 BSP
 Doppelnippel, Edelstahl
AG 1/4 BSP - 3/ 8 BSP
 Racor inox
M1/4BSP-M3/8BSP
1
7 050 470 501  Té FFF 1/4 inoxydable  Tee, FFF 1/4 (corrosion
resistant steel)
 T-Stück
IG/IG/IG 1/4 Rostfrei
 Te HHH 1/4 inoxidable 1
8 050 102 646  Raccord inox
M1/4BSP-M3/8NPS
(retour circulation)
 Fitting, st ainless steel,
double male,
1/4 BSP - 3/8 NPS
(fluid circulation return)
 Doppelnippel
AG 1/4 BSP - 3/ 8 NPS
(Rücklauf der
Zirkulation)
 Racor inox
M1/4BSP-M3/8NPS
(retorno de circulación)
1
9 903 090 218  Robinet inox
FF 3/8 BSP
 Valve, stainless st ee l,
FF 3/8 BSP
 Absperrhahn, Ed elstahl
IG/IG 3/8 BSP
 Grifo inox HH 3/8 BSP 1
10 050 102 436  Raccord inox
M3/8BSP-M18x125
 Fitting, st ainless steel,
double male,
3/8 BSP - 18 x 125
 Doppelnippel, Edelstahl
AG 3/8 BSP
-M18x1,25
 Racor inox
M3/8BSP-M18x125
1
11 906 314 203  Raccord inox
MM 1/4 BSP
 Fitting, st ainless steel,
double male, 1/4 BSP
 Doppelnippel, Edelstahl
AG/AG 1/4 BSP
 Racor inox MM 1/4 BSP 1
12 903 091 101  Robinet pointeau inox
F1/4BSP
 Needle-valve, stainless
steel, F 1/4 BSP
 Nadelventil, Edelstahl
IG 1/4 BSP

Grifo cierre punzón inox
H1/4BSP
1
13 905 190 414  Raccord coudé
plastique
M1/4BSP-T8x10
 Elbow fitting,
polyacetale,
M1/4BSP-T8x10

Winkelnippel, Kunststoff
AG 1/4 BSP - T 8 x 10
 Racor acodado plástico
M1/4BSP-T8x10
1
14 906 313 202  Etrier  U-bolt  Schelle  Abarcón 2
15 953 010 016  Ecrou HM 6  Nut, HM 6  Mutter HM 6  Tuerca, HM 6 4
16 963 040 016  Rondelle M 6  Washer, M 6  Scheibe M 6  Arandela, M 6 4
17 539 090 103  Tuyau noir T 8 x 10
longueur : 300 mm
 Hose (black), T 8 x 10
length : 300 mm / 12 "
 Schlauch, schwarz
T8x10
Länge : 300 mm
 Tubería (negra) T 8 x
10
longitud : 300 mm
1
22 050 470 501  Té FFF 1/4 inoxydable  Tee, FFF 1/4, corrosion
resistant steel
 T-Stück IG/IG/IG 1/4
rostfrei
 Te HHH 1/4 inoxidable 1
23 905 190 414  Raccord coudé
plastique
M1/4BSP-T8x10
 Elbow fitting,
polyacetale,
M1/4BSP-T8x10

Winkelnippel, Kunststoff
AG 1/4 BSP - T 8 x 10
 Racor acodado plástico
M1/4BSP-T8x10
1
24 050 112 201  Ajutage inoxydable  Adjustage, corrosion
resistant steel
 Enschraubkegel, rostfrei  Ajutaje in oxidable 1
25 050 271 303  Ecrou inoxydable
18 x 125
 Nut, corrosion resistant
steel, 18 x 125
 Mutter, rostfrei
M18x1,25
 Tuerca inoxidable
18 x 125
1
