Kremlin-Rexson PMP 150 - Installation

KREMLIN REXSON - 2 - N° : 578.028.120-UK-1309
 DIMENSIONS
Ind. mm " Ind. mm " Ind. mm " Ind. mm " Ind. mm "
A 360 14.2 B 190 7.48 C 240 9.45 D 150 5.9 E 40 1.57
3. INSTALLATION
The pumps are designed to be installed in a spray booth.
 DESCRIPTION OF THE LA BEL MARKING
Marking in accordance with
the ATEX directive
KREMLIN REXSON
93 245 Stains FRANCE
Name and address of the manufacturer
PMP 150
Pump model
CE
European conformity
II 2 G
II : group II 2 : class 2
Surface equipment meant to area where explosive atmospheres due to ga s,
vapours, mists are liable to appear from time to time in usual operating.
G : gas
P air : 6bar / 87 psi
Air and fluid supply maximum pressure
P prod : 6bar / 87 psi
Fluid supply maximum pressure
