KREMLIN REXSON Page 7 Manual : 573.191.112
5. TECHNICAL FEATURES
Number of colors : 1 or 3
Number of catalyst : 1
Solvent paints compatibility
Piloting via magnet on the control bay
Voltage : 230V / 115V - 10W
Minimum air pressure : 4 bar / 58 psi
Fluid pressure: from 2 to 175 bar / from 29 to 2538 psi
Weight : 25 kg / 55 lb
Dimensions :
- control bay : 370 mm x 172.5 mm x 110 mm
/ 14.6" x 6.8" x 4.3"
- fluid module : 370 mm x 460 mm x 110 mm
/14.6"x18.1"x4.3"
Fluid circuits (base and cata) made of stainless steel for
the Cyclomix
TM
Micro and Micro+.
CATALYST circuit made of 316 L stainless steel Circuit
for the Cyclomix
TM
Micro+ PH.
Adjustable mixing ratio : 1/0 and from 0,6/1 to 20/1 (BASE
volume / CATALYST volume) (0% and from 166% to 5%)
Measure precision : 1 %
Mixed fluid flow : from 50 to 2000 cm3/mn
Solvent flow : 7000 cm3/mn
Fluid viscosity : from 30 to 5000 cps
Mixing permanent check
Adjustable threshold alarm
Adjustable pot-life indicator
Automatic mixing control cycle
Automatic flushing cycle (time)
VOC display
Total indicator for base, catalyst and solvent
consumption
OPTION :
*Auto-wash (gun support)
You cannot go to production with the auto-wash, no
connection to the machine.
*Print option (connection to a printer)
*Connecting cable (7 m) option
Different versions of the CYCLOMIX
TM
MICRO :
Configurations BASE CATALYST
CYCLOMIX
TM
MICRO
1base+1solvent 1cata
3 bases + 1 solvent 1 cata
CYCLOMIX
TM
MICRO + 1base+1solvent 1cata+1solvent
3 bases + 1 solvent 1 cata + 1 solvent
CYCLOMIX
TM
MICRO+ PH 1base+1solvent 1cata+1solvent
3 bases + 1 solvent 1 cata + 1 solvent
The control bay is the same for all the versions of the CYCLOMIX
TM
MICRO.
You can change the configuration displacing the shunt located on the μ card (J7 terminal)
- (refer to"Annexes" - electric diagram, folio 2).
