Kreyer – Picture guide to installation and start-up Chilly (page 10 of 18) v.11-2015
Check the electrical diagram of the chiller appearing at the end of the instruction manual where to
connect the cable of the solenoid valve (in this example here the contact inside the control cabinet is
X2 -> clips 5, 6 and 7=earth). It doesn’t matter whether you connect the brown or the blue cable to
clip 5 or 6:
Please check and compare volage on name plate with your local voltage – if not correlating
please contact your supplier!
- End of the optional overflow protection kit -
