14. ACTIVATION OF THE OVERLOAD FUNCTION
13. DRIVE REACTION TO OVERLOAD
15. SENSITIVITY OF OVERLOAD ADJUSTMENT
Press the P2
programming button.
Press the P2
programming button.
Press the P2
programming button.
e roller shutter makes
short up/down movements.
e LED will flash once.
e roller shutter makes
short up/down movements.
e LED will flash once.
e roller shutter makes
short up/down movements.
e LED will flash once.
e roller shutter makes short
up/down movements. e LED
will flash once.
e roller shutter makes
short up/down movements.
e LED will flash once.
e roller shutter makes
short up/down movements.
e LED will flash once.
Press the
STOP button.
Press the
DOWN button.
Press the
STOP button.
Press the
DOWN button.
Press the
DOWN button.
Press the
UP button.
If the roller shutter makes two short up/down
movements, the LED will flash three times; this
means the overload functions has been activated.
If the roller shutter makes two short up/down
movements, the LED will flash three times;
this means that response 1 is activated: after
having detected any obstacles, the drive stops.
e LED blinks and the number of LED flashes (1-6)
which indicates the set sensitivity level.
If the roller shutter makes short up/down movements,
the LED will flash once; this means the overload functions
has been disabled.
If the roller shutter makes short up/down movements,
LED will flash once; it means that response 2 is activated:
after having detected any obstacles, the drive will make
a short movement in the opposite direction.
e overload function is not active for 2 seconds after the drive has started. By default, the overload function is disabled.
1. e switchboard has a six-step overload adjustment scale. Level 1 is the most sensitive overload
and level 6 the least sensitive overload.
2. e second sensitivity level is set by default.
B
B
B
B
A
A
A
A
A
A
Turn off the
power and turn
it on again.
Turn off the
power and turn
it on again.
Turn off the
power and turn
it on again.
