Fig. 13: Connection with humidifier
8 Connect the oxygen tubing to the
humidifier.
NOTE!
The humidifier can be used
directly at the oxygen concentrator
or with the kit for external
humidification (near to the
patient).
Fig. 14: Completely assembled system
9 Completely assembled system
a. Oxygen concentrator
b. Humidifier
c. 0.33 m safety hose
d. Firesafe valve
e. 2 m oxygen nasal cannula
f. Mains connection
WARNING! Danger of tripping over!
On the back of the Kröber O2 you will find a winding device for the mains lead.
This should be used when the unit is out of use, to avoid any danger of tripping
over.
Oxygen safety tubes and nasal cannulas should always be laid in such a way
that they do not represent any tripping or strangulation traps for third parties!
