Taking into service
EN 77
7.3.2 With external humidification
If the unit does not need to stand next to the user, the installation is carried out as follows:
Fig. 15. Mains lead
1 Connect the Kröber O2 to mains.
ATTENTION!
The Kröber O2 is only designed
for operation on a 230 Volt, 50Hz
mains network.
Fig. 16. Adapter for ext. humidification
2 Screw the angle connection to the
oxygen outlet of the Kröber O2 with a
wrench (metric size 17).
ATTENTION! Fire safety!
The metal oxygen outlet must be
installed at all times!
Fig. 17. Oxygen outlet connector
3 Connect the oxygen outlet
connector.
