Kröber O2 - Kröber O2 Vers. 4.0
Taking into service
EN 79
Fig. 21: Humidifier bracket
9 Stand the humidifier into the bracket
(1).
NOTE!
The bracket has the function of
preventing the humidifier from falling
over. It is therefore recommended to
mount the bracket to a wall, a
cupboard, etc.
Fig. 22: Connection to the nasal cannula
10 Plug the FireSafe Nozzle in oxygen
flow direction into the nasal cannula.
ATTENTION!
Observe flow direction indicated
by the arrow!
ATTENTION!
For the best protection of the
patient, place the FireSafe Nozzle
in the oxygen tubing routing as
close to the patient as possible!
11 Connect the other terminal to the
short oxygen tubing (0.33 m).
1
Nasal cannula
Oxygen hose
