5 Start-up
Pos: 3.43 /Übersc hriften/Übersc hriften 2/P-T/T erminal in Ka bine einbauen @ 47\mod_1285 163419265_6.d ocx @ 4558 49 @ 2 @ 1
5.1 Installing the terminal in the cab
Pos: 3.44 /Bei packs/Sonstige/Del ta-Termin al/Einbau in der Kabine Bild @ 1 35\mod_1351 672019386_6.d ocx @ 1202275 @ @ 1
Fig.
3
Pos: 3.45 /Bei packs/Sonstige/Del ta-Termin al/Einbau in der Kabine @ 135\m od_135167209 5595_6.docx @ 1202454 @ @ 1
• Assemble the device support
• Mount the device support on the frame and on the terminal
• Select a suitable location in the tractor cab (in the field of view of the driver) where you
want to attach the terminal
• Fasten the terminal with the device support in the tractor cab
Instruction
Ensure that the screws are tightened firmly.
Instruction
Attach the terminal so that it is clearly legible and easy to operate and that neither the view to
operating elements of the tractor nor to the outside is impeded.
