28
5.3 Supplies
5.3.1 Label Stock
K4350/4350C is capable of both direct thermal and thermal transfer printing.
Many different direct thermal or thermal transfer stocks can be used. Refer to the
following list for specifications of compatible label media.
Media
Specification
Label Tag
Min. 0.22” (5.6 mm)
Paper Width
Max. 3.97” (100.8 mm)
Paper Weight Less than 240 g/m
2
Length (Pitch) 0.4” (10 mm) ~ 40” (1016 mm)
Thickness 0.002” (0.05 mm) ~ 0.008” (0.20 mm)
Inner roll diameter. Max. 4.3” (110 mm)
Max. Roll Diameter.
(1” core)
External roll diameter. Max. 8.4” (214 mm)
Roll Up Method Print surface is wound outside as standard
Paper Core ID.
φ25.7 ± 0.3 mm
5.3.2 Ribbon
Standard 300m by 60 or 110mm thermal transfer ribbons with wax, wax-resin, or
resin coating (wound outside) are available from Kroy. Of ribbon selection, it is
recommended that the ribbon be at least as wide as the print media. Also, the
ribbon end should be transparent.
