Fan Powered Terminal Units IOM
Set
Point
CFM
MANUAL %
Display
(option 6)
REMOTE 0-10Vdc (0-20mA)
DC Signal (option 7)
REMOTE 2-10Vdc (4-20mA)
DC Signal (option 8)
2000 100 10 (20.0) 10 (20.0)
1980 99 9.9 (19.8) 9.9 (19.8)
1960 98 9.8 (19.6) 9.8 (19.7)
1940 97 9.7 (19.4) 9.8 (19.5)
1920 96 9.6 (19.2) 9.7 (19.4)
1900 95 9.5 (19.0) 9.6 (19.2)
1880 94 9.4 (18.8) 9.5 (19.0)
1860 93 9.3 (18.6) 9.4 (18.9)
1840 92 9.2 (18.4) 9.4 (18.7)
1820 91 9.1 (18.2) 9.3 (18.6)
1800 90 9.0 (18.0) 9.2 (18.4)
1780 89 8.9 (17.8) 9.1 (18.2)
1760 88 8.8 (17.6) 9.0 (18.1)
1740 87 8.7 (17.4) 9.0 (17.9)
1720 86 8.6 (17.2) 8.9 (17.8)
1700 85 8.5 (17.0) 8.8 (17.6)
1680
84 8.4 (16.8) 8.7 (17.4)
1660 83 8.3 (16.6) 8.6 (17.3)
1640 82 8.2 (16.4) 8.6 (17.1)
1620 81 8.1 (16.2) 8.5 (17.0)
1600 80 8.0 (16.0) 8.4 (16.8)
1580 79 7.9 (15.8) 8.3 (16.6)
1560 78 7.8 (15.6) 8.2 (16.5)
1540 77 7.7 (15.4) 8.2 (16.3)
1520 76 7.6 (15.2) 8.1 (16.2)
1500 75 7.5 (15.0) 8.0 (16.0)
1480 74 7.4 (14.8) 7.9 (15.8)
1460 73 7.3 (14.6) 7.8 (15.7)
1440 72 7.2 (14.2) 7.8 (15.5)
1420 71 7.1 (14.0) 7.7 (15.4)
1400 70 7.0 (13.8) 7.6 (15.2)
1380 69 6.9 (13.6) 7.5 (15.0)
1360 68 6.8 (13.6) 7.4 (14.9)
1340 67 6.7 (13.4) 7.4 (14.7)
1320 66 6.6 (13.2) 7.3 (14.6)
1300 65 6.5 (13.0) 7.2 (14.4)
1280 64 6.4 (12.8) 7.1 (14.2)
1260 63 6.3 (12.6) 7.0 (14.1)
1240 62 6.2 (12.4) 7.0 (13.9)
1220 61 6.1 (12.2) 6.9 (13.8)
1200 60 6.0 (12.0) 6.8 (13.6)
1180 59 5.9 (11.8) 6.7 (13.4)
1160 58 5.8 (11.6) 6.6 (13.3)
1140 57 5.7 (11.4) 6.6 (13.1)
1120 56 5.6 (11.2) 6.5 (13.0)
1100 55 5.5 (11.0) 6.4 (12.8)
1080 54 5.4 (10.8) 6.3 (12.6)
1060 53 5.3 (10.6) 6.2 (12.5)
1040 52 5.2 (10.4) 6.2 (12.3)
1020 51 5.1 (10.2) 6.1 (12.2)
Set
Point
CFM
MANUAL %
Display
(option 6)
REMOTE 0-10Vdc (0-20mA)
DC Signal (option 7)
REMOTE 2-10Vdc (4-20mA)
DC Signal (option 8)
100 50 5 (10.0) 6.0 (12.0)
980 49 4.9 (9.8) 5.9 (11.8)
960 48 4.8 (9.6) 5.8 (11.7)
940 47 4.7 (9.4) 5.8 (11.5)
920 46 4.6 (9.2) 5.7 (11.4)
900 45 4.5 (9.0) 5.6 (11.2)
880 44 4.4 (8.8) 5.5 (11.0)
860 43 4.3 (8.6) 5.4 (10.9)
840 42 4.2 (8.4) 5.4 (10.7)
820 41 4.1 (8.2) 5.3 (10.6)
800 40 4 (8.0) 5.2 (10.4)
780 39 3.9 (7.8) 5.1 (10.2)
760 38 3.8 (7.6) 5.0 (10.1)
740 37 3.7 (7.4) 5.0 (9.9)
720 36 3.6 (7.2) 4.9 (9.8)
700 35 3.5 (7.0) 4.8 (9.6)
680 34 3.4 (6.8) 4.7 (9.4)
660 33 3.3 (6.6) 4.6 (9.3)
640 32 3.2 (6.4) 4.6 (9.1)
620 31 3.1 (6.2) 4.5 (9.0)
600 30 3 (6.0) 4.4 (8.8)
580 29 2.9 (5.8) 4.2 (8.6)
560 28 2.8 (5.6) 4.2 (8.5)
540 27 2.7 (5.4) 4.1 (8.3)
520 26 2.6 (5.2) 4.0 (8.2)
500 25 2.5 (5.0) 3.9 (8.0)
480 24 2.4 (4.8) 3.8 (7.8)
460 23 2.3 (4.6) 3.8 (7.7)
440 22 2.2 (4.4) 3.6 (7.5)
420 21 2.1 (4.2) 3.7 (7.4)
400 20 2 (4.0) 3.6 (7.2)
380 19 1.9 (3.8) 3.5 (7.0)
360 18 1.8 (3.6) 3.4 (6.9)
340 17 1.7 (3.4) 3.4 (6.7)
320 16 1.6 (3.2) 3.3 (6.6)
300 15 1.5 (3.0) 3.2 (6.4)
280 14 1.4 (2.8) 3.1 (6.2)
260 13 1.3 (2.6) 3.0 (6.1)
240 12 1.2 (2.4) 3.0 (5.9)
220 11 1.1 (2.2) 2.9 (5.8)
200 10 1 (2.0) 2.8 (5.6)
180 9 0.9 (1.8) 2.7 (5.4)
160 8 0.8 (1.6) 2.6 (5.3)
140 7 0.7 (1.4) 2.6 (5.1)
120 6 0.6 (1.2) 2.5 (5.0)
100 5 0.5 (1.0) 2.4 (4.8)
80 4 0.4 (0.8) 2.3 (4.6)
60 3 0.3 (0.6) 2.2 (4.5)
40 2 0.2 (0.4) 2.2 (4.3)
20 1 0.1 (0.2) 2.1 (4.2)
CFM VALUES BELOW RECOMMENDED MINIMUM MAY AFFECT LIFE OF MOTOR.
TABLE 15: KQFS / KQFS-FA Size 6 ECM CALIBRATION
